Fabricated with heavy-gauge AISI SS 304/316 food-grade stainless steel, engineered for 24/7 continuous hygienic operation, high thermal efficiency, and minimal dairy maintenance.
Vertical milk storage tank and silos are known for being sturdy, heat resistant, and having a long life. They are often used in milk processing industries. Vertical milk storage Tanks &silos can come in many different sizes and capacities, ranging from 1 KL to 150 KL.They are made up of a painted steel or stainless-steel outer shell with a stainless-steel inner liner. Vertical milk storage tanks are manufactured in compliance with Dairy industries norms and standards. Some features to consider when buying a vertical milk storage tank include.
Vertical silo tanks are often placed outside the processing section to avoid tall buildings. The inner shell of the storage tank is made of stainless steel, covered with suitable insulation, and then an outer shell, which may be stainless steel or mild steel.
| Temperature control | Multi Layers Insulated for Maintain Chilled Temp at 4°C |
| Tank | Durable, AISI-304 S.S. Tanks with insulation |
| Maintenance | User-friendly, low maintenance |
| Sensors | Level Sensor & Pressure Level Sensor for Automation |
| Agitator | Top & Side Mounted Agitator Continuously rotates milk to maintain a uniform state |
| Capacity Range | Vertical milk storage tanks and silos come in varying capacities, such as 1000 liters, to 150,000 Liters catering to the diverse needs of dairy farms and processing units. |
| Gross capacity | 10% Extra for Rated Capacity |
| Construction of Tank | AISI SS 304 |
| Tank Orientation | Vertical Type &completely closed type in Shape of Round. |
| Base Structure | A Heavy Duty Mild Steel Structure with Two Coats Epoxy Primary theBase Structure can Stand with Load Capacity with Fully Filled Silos without any Damage. |
| Inner Body | AISI SS 304 |
| Outer Body | AISI 304 |
| Milk measuring facility | High / Low Sensor, Pressure Level Sensor &Inside Wall Level Marking Visible from Sight Glass |
| Agitators | Heavy Duty Gear Motors Top and Side Mounted Agitators to Uniform Mixing Milk/Liquid |
| Type of Insulation | Liquid Puff Injected or Multi Layers Insulation in the Form of Puff Sheet, Thermocol, LRB, Aluminum Foil & Bitumen. |
| CIP Facility | High Speed Rotary Spray Ball for Inside Complete Cleaning |
| Manway | Locking Type Manway Side/Top Mounted with food Grade Silicone Gasket |
| Ball Fit | Adjustable 50 mm Height Solid Ball Fit to Leveling the Tank up to 20 Kl VMST |
| Ladder | Heavy Duty Ladder made from Steel Pipes & Plates to approaching Top of Silos |
| Reeling | Steel Pipe Reeling at Top of Silos |
| Air vent | an Air vent top Mounted to Prevent Vacuums Generation During Milk Pump Milk Out Process |
| Temperature Sensor | STD Thermowell PT 100with ½” BSP Coupling SS 304 |
| Inlet | No Foam Inlet with Expandable Union |
| Light / Sight Glass | Light Glass with LED Bulb & Sight Glass for Check Milk Level Marking |
| Toe Guard | Fully Weld Toe Guard at Outer Top of Silos |
| Lifting Lugs | Heavy SS 304 Cladded Lifting Lugs to Liftin Silos. |
| Milk Outlet | SS 304 Flange Type Butter Fly Valve for Taking Out Milk |
| Bird Cage | A SS 304 Wire Mesh or Perforated Sheet Made Bird Cage for Cleaning & Avoid Bird to Contact Agitator & Other Parts |
| Automation | Imported High Priscian Level Sensors &Pressor Level Transmitter Sensorsfor Exact Value of Milk Quantity in Milk Silo direct to Display in Control Panel in Plants & Office Area. |
| Sampling Cock | 1” Inch Sampling Cock to Take Sample of Milk to Examine in Laboratory |
Authoritative technical answers regarding capacity sizing, food-grade sanitary construction, Clean-In-Place (CIP) cleaning, and dairy plant integration from Aviva Equipments engineers.
A vertical milk storage tank maximizes plant storage capacity while occupying a compact factory footprint. Outdoor vertical milk silos can store massive volumes (up to 150,000 Litres) without demanding expensive indoor factory building space.
We construct the inner tank shell from food-grade AISI SS 304 or SS 316 stainless steel with automated circumferential TIG welding and Ra < 0.4 µm internal mirror polish, preventing any bacterial buildup or milk residue adhesion.
Aviva equips vertical silos with precision-engineered side agitators featuring sanitary mechanical seals and hydrofoil blades that gently circulate the entire milk volume at 300 RPM without causing buttering or aeration.
Every silo features an engineered top pressure/vacuum relief valve, overflow pipe, high and low-level radar transmitters, a top safety cage ladder with catwalks, and dual high-flow rotary CIP spray balls.
As a certified milk silo manufacturer, Aviva provides end-to-end design, civil foundation guidance, heavy crane erection, sanitary piping integration, and automated PLC level telemetry.
Consult with Aviva Equipments engineering team for custom capacity sizing, P&ID layout drawings, and factory-direct pricing tailored to your plant.
