Fabricated with heavy-gauge AISI SS 304/316 food-grade stainless steel, engineered for 24/7 continuous hygienic operation, high thermal efficiency, and minimal dairy maintenance.
A Bulk Milk Cooler (BMC) is a large storage tank used by dairy Industries to Chilling Raw Milk. It’s a Main Part of dairy Industry& Dairy Products Process Plants, These Tanks usually made from stainless steel, and is cleaned by CIP after Complete each milk collection. AEPL is top bulk milk cooler manufacturer in India. Our 10K L BMC have an enclosed design with an automatic cooling control unit and a Compact Control Panel with digital display to Easily Operate Complete BMCU System. The tank Having a 100 mm Thickness Polyurethane foam Insulation (Density 40 Kg)Injected by Machine. To Maintain Chilled Milk at Temp 4°C AEPL 10KL BMC Deigned by Special Construction, which allows them to Chilled milk 20 times faster. BMC have an 02Nos Agitator with the RPM 30- 32, to ensures the milk is the same temperature throughout the Day and prevents warm milk in the middle.
| Temperature control | Digital temperature controller, advanced digital Technology to Control & Maintain temperature |
| Cooling | Faster cooling due to direct expansion, energy efficient condensing unit |
| Tank | Durable, AISI-304 S.S. Tanks with insulation |
| Maintenance | User-friendly, low maintenance |
| Electricity | Reduced electricity consumption |
| Protection | Inbuilt anti-freezing protection system |
| Microprocessor | Maintains temperature |
| Agitator | Continuously rotates milk to maintain a uniform state |
| Rated capacity | 10,000 liters |
| Gross capacity | 10,500 liters |
| Construction of Tank | AISI SS 304 |
| Tank Orientation | completely closed type in Shape of Elliptical & Horizontal |
| Tank Evaporator | Omega Make Laser welded with Operating pressure of 30 bars and crash test pressure of 60 bars. |
| Inner thickness | 2.5 mm AISI SS 304 |
| Outer thickness | 1.5 mm AISI 304 |
| Milk measuring facility | Inside Wall Mounted Dip stick &Calibration accuracy- 0.5%. Laminated & Framed calibration chart. |
| Agitators | 02 Nos Heavy Duty Gear Motor Type Agitators to Maintain Milk Temp & Compliance ensuring evendistribution of the milk fat. |
| Type of Insulation | 100 mm thkInjected, CFC Free PUF 40kg/Cu. m. with the 0.019 Wm/k |
| CIP Facility | Rotary Spray Ball 03 Nos for Inside Complete Cleaning |
| Voltage range | Input Volts: 300 to 550 for 3-phase BMC Out Put Volts: 415 |
| Manway | Locking Type Manway Top Mounted |
| Ball Fit | Adjustable 50 mm Height Solid Ball Fit to Leveling the Tank |
| Ladder | Front Side Heavy Duty Ladder made from Pipes & Plates to approaching manway |
| Air vent | an Air vent top Mounted to Prevent Vacuums Generation During Milk Pump Milk Out Process |
| Temperature Sensor | Sub Zero |
| Inlet | No Foam Inlet |
| Pipe Line & Accessories | SS 304 Dairy Standard Union, NRV, 3 Way Valves etc. to Smooth Milk Loading Unloading Process in BMC. |
| Servo Stabilizer | - 62.5 KVA – 3 Phase |
| D.G Set Require | 62.5 KVA (Optional on Demand) - 3 Phase |
Standard Applicable Cooling Time – First milking cycle (appx 50% of rated capacity of BMC tank) Cooling in less than 3 hours from 35C to 4°C- Second milking cycle (appx.50% of rated capacity of BMC tank) cooling in 3 hour (average temp 19.5 C to4°C)
Authoritative technical answers regarding capacity sizing, food-grade sanitary construction, Clean-In-Place (CIP) cleaning, and dairy plant integration from Aviva Equipments engineers.
A 10KL closed-type bulk milk cooler serves as a centralized milk chilling hub for clusters of village societies. It holds 11,000L gross volume, eliminating multiple small coolers and significantly lowering operating costs per liter of chilled milk.
The tank features a multi-circuit laser-welded Omega dimple evaporator along the entire lower half of the shell, powered by twin or triple tandem condensing units for maximum thermal transfer and built-in refrigeration redundancy.
Aviva offers automated PLC touch panels with GSM/IoT milk volume and temperature telemetry. Dairy plant managers can monitor real-time chilling temperatures, power status, and milk quantity directly via smartphone or web dashboard.
To withstand 10 metric tons of liquid weight, Aviva fabricates the inner shell from 2.5mm AISI SS 304 and outer cladding from 1.5mm SS 304, reinforced with internal stiffener rings and heavy tubular support legs with leveling ball feet.
Aviva Equipments is a leading bulk milk cooler manufacturer in india providing turnkey logistics, hydraulic crane unloading, factory-certified leveling, refrigeration vacuum testing, and on-site commissioning.
Consult with Aviva Equipments engineering team for custom capacity sizing, P&ID layout drawings, and factory-direct pricing tailored to your plant.
