Ghee storage and settling tanks

Ghee storage and settling tanks

Ghee storage & Settling tanks are used by dairy plants to safely store melted ghee.Ghee storage tank is specialized containers designed for storing & Settling ghee, a clarified butter commonly used in cooking. These tanks play a crucial role in the dairy industry’s ghee production process.

ghee storage tank
ghee storage tank

Features

  • Purpose: -Ghee storage tank is utilized for storing and settling ghee.
  • Construction: -These tanks are likely constructed with Materials include SS316, SS304, and SS316L stainless steelto maintain the quality and purity of the stored ghee.
  • Size & Capacity: -Ghee storage tanks are Available in various sizes and capacitiessuch as 500-5000-liter, catering to the diverse production needs of dairy facilities.
  • Cooling & Maturing: -Some tanks are also facilitate cooling Facility, contributing to the maturation process of the ghee.
  • Industry Application: -Industries such as dairy processing and ghee manufacturing extensively use these specialized storage Tanks.
  • Ghee Storage Tanks are widely used in different food processing industries for storing Ghee. These Ghee Storage Tanks are fabricated under the stringent supervision of our workforce. High-tech machinery is used at the time of making these Ghee Storage Tanks

Technical Specifications

Design: Unique, Occupies minimal space

  • Capacity Range: Vertical Ghee storage tanks comes in varying capacities, such as 500 liters, to 5,000 Liters catering to the diverse needs of dairy farms and processing units.
  • Gross capacity: 10% Extra for Rated Capacity
  • Construction of Tank: AISI SS 304, AISI SS 316 & AISI SS 316L
  • Tank Orientation– Vertical Type &Commonly Open &closed type in Shape of Round.
  • Design –These tanks are having Double or Triple Jacket. for Steam or Hot Water Circulation to Maintain Ghee Temperature.
  • Inner Body: AISI SS 316
  • Outer Body: AISI 304
  • Milk measuring facility: Sand Blasted Level Marking every 500 L Intervals
  • Agitators–Heavy Duty Top Mounted Gear Motor with Single Piece Solid SS Rod with Sweeping Types Agitator for Proper Mixing Ghee.
  • Type of Insulation–Light Raising Bond. LRB – 50-125 mm Thk
  • CIP Facility–High Speed Rotary Spray Ball for Inside Complete Cleaning
  • Manway& Cover– Locking Type ManwayTop Mounted with food Grade Silicone Gasket& Some Tanks are Comes in Two Side Openable Covers
  • Chilled Water Inlet Header –Jacketed also Having a Chilled Water Flow Header to Maintain Temperature of Ghee.
  • Condensate Out for Steam –A Float Type Steam Trap System for Automatic Drain Steam Condensate in jackets.
  • Ball Fit– Adjustable 50 mm Height Solid Ball Fit to Leveling the Tank
  • Ladder–Heavy Duty Ladder made from Steel Pipes & Plates to approaching Top of Tanks
  • Air vent– an Air vent top Mounted to Prevent Vacuums Generation During Milk Pump Milk Out Process& Release Moisture in Tanks
  • Temperature Sensor–STD Thermowell PT 100with ½” BSP Coupling SS 304
  • Inlet– No Foam Inlet with Expandable Union
  • Light / Sight Glass– Light Glass with LED Bulb & Sight Glass for Check Milk Level Marking
  • Lifting Lugs– Heavy SS 304 Cladded Lifting Lugs to Liftin Silos.
  • Bottom Drain Outlet– SS 304 Two Way Plug Valve to Drain Complete Ghee.
  • Side Outlet– SS 304 Two Way Angle Valve with Flow Control System to Take Fresh Ghee During Process.
  • Automation– Imported High Priscian Level Sensors &Pressor Level Transmitter Sensorsfor Exact Value of Ghee Quantity and Transit direct to the Display in Control Panel in Plants & Office Area.
  • Sampling Cock– 1” Inch Sampling Cock to Take Sample of Milk to Examine in Laboratory
  • Hot Water & Steam Inlet Connection –in Jacketed Tanks Flange Type Seamless Hot & St
